The Best Has Arrived: See What ASRock Rack Has Got Lined Up For Intel^® Xeon^® Scalable Processor Platform

Taipei, Taiwan, July 12, 2017

As Artificial Intelligence (AI) becomes more pervasive in the market, ASRock Rack is introducing 5 new motherboard designs based on the new Intel^® Xeon^® Scalable Processor platform and can deliver up to 2.2x more machine learning inference and training performance for AI.

The new Intel^® Xeon^® Scalable Processor marks a significant milestone in processor architecture for Intel, with upgrades from AVX2 to AVX-512 instructions, and a 1.5 times increase in memory bandwidth from 4 to 6 channels. This new processor supports an integrated host fabric interface (HFI), and up to 100Gbp bandwidth with the Omni-Path architecture. It significantly improves scalability and resilience with new IO capabilities by expanding to 48 PCI-E lanes which allows more possibilities for hardware acceleration and high-end storage. Meanwhile, the server platform supports Intel^® Ethernet Connection X722 which has 4x10GbE with RDMA.

In collaboration with Intel, ASRock Rack has launched 7 different, new server motherboards and 2 barebone systems based on the Intel^® Xeon Scalable Processor. Each different motherboard has targeted market segments served by a variety of form factors from rack, to blade and pedestal. ASRock Rack's goal is to always provide leading server technology and to provide the ability to upgrade a wide suite of existing applications.

EPC622D24LM

Key Segments and Specification

• Enterprise Mission Critical Application / Datacenter / E-commerce / Virtualization
• L shape 16.7"x17"
• Dual Socket P support Intel^® Xeon^® Scalable Processor
• 24 xDDR4 2600/2400 R or LR DIMM slots
• 14 x SATA3 6.0Gb/s by Intel^® C622 ( Incl. 2xM.2 slots)
• 2 x PCI-E3.0x16 (Slot1:x16 CPU0, Slot2:x16 from CPU1), 1xPCI-E3.0x8 from CPU1
• 5xUSB3.0 ports(2 ports in rear side, 2 ports from internal header, 1 port internal type A)

EP2C622D16NM

Key Segments and Specification

• High Performance and High-density HPC / Mission Critical / Hyper Converge / Database or Haddop Server with SSD Acceleration / I/O virtualization / Co-location
• EEB 12"x13"
• Dual Socket P support Intel^® Xeon^® Scalable Processor
• 16 xDDR4 2600/2400 R or LR DIMM slots
• 14 x SATA3 6.0Gb/s by Intel^® C622 ( Incl. 1xSATA DOM ports and 1xM.2 slots)
• 2 x PCI-E3.0x16
• Support OCP Mezzanine type A/B/C

EPC621D8A

Key Segments and Specification

• UP Solution for Application Server / High-end Workstation / GPGPU Server / Multi-display Server
• ATX 12" x 9.6"
• Single Socket P supports Intel^® Xeon^® Scalable Processor
• 8 x DDR4 2666/2400 R and LRDIMM slots
• 14 SATA3 6.0 Gb/s by Intel^® C621(Incl.1 x SATA DOM and 1 x M.2)
• 2 x PCI-E3.0x16, 3 x PCI-E3.0x8. 1 x PCI-E3.0 x4

EP2C622D24HM

Key Segments and Specification

• HPC Application / Scientific Computing / Real-time Finance / Research & Labs
• Half Width (OCP Blade) 6.5" x 20"
• Supports Intel^® Xeon^® Scalable Processor ( with FPGA package TDP 205W)
• 24 x DDR4 2666/2400 RDIMM/ LR DIMM
• Intel^® C622: 13 x SATA3 (by 3x mini SAS HD, 1xM.2)
• 1 x PCI-E3.0x24, 1 x PCI-E3.0x8
• 1 x USB3.0 port
• Support OCP Mezzanine type A/B/C

EP2C622D16HM

Key Segments and Specification

• High Performance Computing Node / Virtualization Server / DPI Server / Internet Security
• Half 20" x 6.5"
• Dual Socket P support Intel^® Xeon^® Scalable Processor
• 16 x DDR4 2666/2400 R and LRDIMM
• 14 SATA3 6.0 Gb/s by Intel^® C622 (Incl.1 x SATA DOM and 1 x M.2)
• 2 x PCI-E3.0x16

EP2C622D16FM

Key Segments and Specification

• High Performance Server / High-density CPU Rendering Machine / Scale-out HPC Platform / GPGPU Server
• SSI CEB 12" x 10.5"
• Intel^® Xeon^® Scalable Processor
• 14 SATA3 (12 from 3 x miniSAS connector + 2 x M.2 ports from PCH)
• 2 x USB3.0 ports
• Integrated IPMI2.0 with KVM and dedicated LAN(RTL8211E)
• Support OCP Mezzanine type A/B/C

EP2C622D12HM

Key Segments and Specification

• High Performance Computing Node / Virtualization Server / DPI Server / Internet Security
• Half Width(OCP Blade)6.5"x20"
• Intel^® Xeon^® Scalable Processor
• 13 SATA3 (12 from 3 x miniSAS connector + 1 x sSATA shared with M.2)
• 1xPCI-E3.0x24, 1xPCI-E3.0x8
• 1 x USB3.0 ports
• Support OCP Mezzanine type A/B/C

1U12LX-C622RPSU

Key Segments and Specification

• High-density Web 2.0 Cloud Datacenter Storage
• 1U Chassis support 12x3.5'' SATA3/SAS2 HDD Hot-Swap Bay +2 x 2.5'' HDD Bay with 700W Redundant PSU
• Intel^® Xeon^® Scalable Processor
• Supports Dual Channel DDR4 2133/2400/2666 RDIMM,LR DIMM,NV DIMM ECC , 16 slots
• Support 14 x SATA3 by C622
• ASPEED 2500. Integrated IPMI 2.0 with KVM, vMedia and Dedicated LAN (RTL8211E)
• Supports 2 x x8 Mezzanine slot & typeC slot support OCP mezzanine card

1U12LX-C622SPSU

Key Segments and Specification

• High-density Web 2.0 Cloud Datacenter Storage
• 1U Chassis support 12x3.5'' SATA3/SAS2 HDD Hot-Swap Bay +2 x 2.5'' HDD Bay with 700W Single PSU
• Intel^® Xeon^® Scalable Processor
• Supports Dual Channel DDR4 2133/2400/2666 RDIMM,LR DIMM,NV DIMM ECC , 16 slots
• Support 14 x SATA3 by C622
• ASPEED 2500. Integrated IPMI 2.0 with KVM, vMedia and Dedicated LAN (RTL8211E)
• Supports 2 x x8 Mezzanine slot & typeC slot support OCP mezzanine card
